Features

Users can set data storage periods based on specific requirements.

The analyzer allows for the configuration of measurement parameters according to specific monitoring needs.

The analyzer automatically identifies sensors, making them ready for immediate use upon insertion.

The analyzer supports the connection of up to 9 sensors, providing flexibility and scalability for monitoring multiple parameters.

The analyzer facilitates full-program operation with intuitive prompts, ensuring ease of use.

Technical Specifications

Conductivity:

Detection Range: 0 ~ 20000 μS/cm

Detection Principle: Dual-electrode conductivity measurement

Temperature Compensation: Automatic temperature compensation using built-in NTC temperature sensor

Resolution: 0.01 μS/cm ( 20 μS/cm) , 0.1 μS/cm ( 200 μS/cm) , 1 μS/cm ( 2000 μS/cm) , 10 μS/cm ( 20000 μS/cm)

Protection Level: IP68 (Sensor & Cable)

Response Time: T90 < 60 seconds

Turbidity:

Detection Range: 0 ~ 1000 NTU , 0 ~ 4000 NTU

Detection Principle: 90° scattered light

Protection Level: IP68 (Sensor & Cable)

Resolution: 0.01 NTU

Dissolved Oxygen:

Detection Range: 0 ~ 20 mg/L

Detection Principle: Fluorescence Method

Response Time: T90 < 60 seconds

Temperature Compensation: Automatic temperature compensation using built-in NTC temperature sensor

pH:

Detection Range: 0 ~ 14 pH

Resolution: 0.01 pH

Response Time: T95 < 10 seconds

Protection Level: IP68 (Sensor & Cable)

Temperature Compensation: Automatic temperature compensation using built-in NTC temperature sensor

Temperature:

Detection Range: -5 ~ 80 ℃

Non-exhaustive list, please contact us if you have any other application inquiries.
